The Perlisten S5t Shares technologies and drivers from the flagship S7t. Featuring their proprietary DPC-Array controlling Mid/High frequencies, centered by a 28mm Beryllium dome and dual 28mm TPCD ultra-lightweight domes.
All transducers are developed ground up by our engineers – bringing decades of research, culminating in this world class design. They have teamed up with companies in the USA and Sweden to bring modern material science to hi-fi.
Utilizing advanced Comsol acoustical modeling, their DPC-array is the result of 18 months of painstaking simulations and prototyping. The result is one of the most technologically advanced loudspeakers available. This new tweeter/waveguide DPC-Array delivers amazing accuracy, smoothness, and directivity control to handle the critical vocal range and delicate treble.
All S-Series speakers share the same DPC-Array and benefit from our unique timbre matching technique across the entire series. Custom bass drivers made from thin-ply carbon diaphragms (TPCD) can be configured as bass reflex or acoustic suspension and adjusted for listener preference. Unparalleled dynamic range, low distortion and musical finesse.
The PerListen S-Series speakers also have the distinguished honor to be the world’s first and only loudspeakers to be certified for THX Dominus – their highest rating. A mark of achievement.
The S5t can also be sealed or vented for the best integration into any room, and the same exquisite DPC array, for THX certified Dominus surround or Ultra LCR home theater applications. Proof that a speaker can do both applications seamlessly.
Perlisten S5t Specifications:
|Enclosure alignment||3-way bass reflex / acoustic suspension|
28mm(2) Textreme TPCDWoofers:
180mm(2) Textreme TPCD
|Sensitivity||89.5dB / 2.83v / 1.0m|
|Impedance||4Ω nominal / 3.0Ω min|
|Response Linearity||80 – 20kHz +/-1.5dB window|
|Frequency Response (-10dB)||Bass reflex: 24 – 32kHz
Acoustic suspension: 36 – 32kHz
|Typical In Room bass extension||Bass reflex: 20Hz
Acoustic suspension: 23Hz
|Dimensions (HxWxD)||1119 x 240 x 400mm
44.1 x 9.5 x 15.8”
|Weight||43.2 kg (95.1 lbs.)|
|Recommended Amplifier Power||100 – 300W RMS|
|SPL capability @1m (100-20kHz)||114.3dB peak
114.0dB peak <3% – 2nd, 3rd Harmonics
|Certification||THX Dominus, THX Ultra|
|Available finishes||Piano Black
